CDS6140B / CDS6240B Manual Horizontal Lathe-Qi Fa (Jiangsu) Machinery Co., Ltd.

CDS6140B / CDS6240B Manual Horizontal Lathe is widely used for:

· Automotive parts machining such as shafts, bushings and mechanical components
· Mold and tooling maintenance operations
· Hydraulic equipment component processing
· Machinery repair workshops and general manufacturing
· Small batch production of metal parts

Versatile Turning Operations
The machine supports external turning, internal boring, facing, drilling, reaming and oil groove processing, meeting different workshop machining needs.

Thread Processing Capability
The enclosed feed box supports metric, inch, module and diametral pitch thread machining for various production requirements.

Rigid Cast Iron Structure
The bed, headstock and carriage use high-strength cast iron components to improve structural rigidity and machining stability.

Precision Guideway Design
The bed guideways are high-frequency hardened and precision ground, helping maintain accuracy during long-term operation.

Stable Spindle System
The spindle system is dynamically balanced to provide smooth operation and support modern cutting tools.

Operator-Friendly Design
The carriage features longitudinal and cross rapid movement functions, while the lead screw is protected by a metal cover to improve operation safety.

PRODUCT NAME		CDS6140B CDS6240B	CDS6150B CDS6250B	CDS6166B CDS6266B		CDS6150C CDS6250C	CDS6166C CDS6266C
CAPACITY
Swing over bed		400mm	500mm	660mm		500mm	660mm
Swing over cross slide		230mm	290mm	440mm		290mm	440mm
Height of centers		1100mm	1130mm	1205mm		1130mm	1205mm
Swing in gap		700mm	760mm	870mm		760mm	870mm
Gap length (from spindle nose)		280mm
Distance between centers		750mm/1000mm/1500mm/2000mm/3000mm
SPINDLE
Spindle nose		D8 or C8 (C-series machine tools are limited to the D8 model)
Taper of spindle bore		90 mm / 1:20				110 mm / 1:20
Spindle centre height		220mm	250mm		330mm	250mm	330mm
Spindle bore		82mm				105mm
No.of Spindle speed		16
Spindle speed ranges		26-2000 rpm				26 - 1700 rpm
Maximum spindle motor power		7.5 kW (10 HP)
BED AND SLIDE
Width over bedways		394mm
Cross slide travel - X axis		348mm			355mm	348mm	355mm
Travel of top slide		150mm
Max.dimension of tool shank		25x25mm
Cros feed		0.022-0.74mm/rev
Longitudinalo feed		0.044-1.48mm/rev
Number of Imperial Pitches		47
Range of Imperial Pitches		7 / 16 - 80TPI
Number of Diametral Pitches		47
Range of Diametral Pitches		7/8 - 160DP
Number of Metric Pitches		73 (53 Imperial-system machine tools)
Range of Metric Pitches		0.35 - 80mm
Number of Module Pitches		45 (66 Imperial-sized machine tools)
Range of Module Pitches		0.2 - 40 MOD
Longitudinal rapid travelling speed		4 m/mim
Traosverse rapid travelling speed		1.5 m/mim
TAILSTOCK
Tailstock quill diameter		75mm
Tailstock quill taper		No 5 MT
Tailstock quill travel		150mm
SPACE AND WEIGHT
Overall machine length		2350mm/2600mm/3100mm/3600mm/3000mm
Overall machine width		1226mm
Overall machine height		1390mm	1440mm	1520mm		1440mm	1520mm
Overall machine weight
Distance between centers	750mm	2070kg	2120kg	2170kg		2120kg	2170kg
	1000mm	2120kg	2170kg	2220kg		2170kg	2220kg
	1500mm	2170kg	2220kg	2270kg		2220kg	2270kg
	2000mm	2280kg	2330kg	2380kg		2330kg	2380kg
	3000mm	3060kg	3110kg	3200kg		3110kg	3200kg
PRODUCT NAME		CDS6140B CDS6240B	CDS6150B CDS6250B	CDS6166B CDS6266B		CDS6150C CDS6250C	CDS6166C CDS6266C

CDS6140B / CDS6240B Manual Horizontal Lathe supports customized solutions for different machining requirements:

· Spindle configuration adjustment
· Center distance customization
· Machine structure adjustment according to workpieces
· Optional handwheel and operation configurations
· Customized accessories and tooling solutions

Item	Details
MOQ	1 set
Standard Lead Time	Around 30 days
Payment Terms	30% T/T deposit, balance before shipment
Shipping Terms	FOB Shanghai, CIF or customized trade terms
Shipping Method	Sea shipment from Shanghai Port
Packaging	Protective wooden case packaging

Standard CNC machines are available for shorter delivery cycles, while special configurations such as 5-axis machines and gantry machining centers are produced according to customer orders.

Each machine is inspected before shipment. The company provides a 12-month whole machine warranty excluding wearing parts, 24-hour online technical support and quality feedback response within 24 hours.

Q1: What materials can CDS6140B / CDS6240B Manual Horizontal Lathe process?

A: It can process steel, cast iron, non-ferrous metals and non-metal materials commonly used in industrial machining.

Q2: What machining operations can this manual lathe perform?

A: It supports turning, boring, drilling, reaming, oil groove processing and different types of thread machining.

Q3: What is the spindle bore size of this model?

A: The CDS6140B model features an 82mm spindle bore design for general machining applications.

Q4: Is this lathe suitable for small batch production?

A: Yes. It is designed for small batch production workshops, repair facilities and general mechanical processing applications.

Q5: What after-sales support is available for CDS6140B / CDS6240B Manual Horizontal Lathe?

A: The machine includes a 12-month warranty, 24-hour online technical support and remote troubleshooting service.
